40 Ahora puede reservar el stock
Cantidad | Precio (sin IVA) |
---|---|
1+ | 52,270 € |
5+ | 45,730 € |
10+ | 37,890 € |
25+ | 33,970 € |
50+ | 31,360 € |
Información del producto
Resumen del producto
The GX-F8A-P is a rectangular-shaped Inductive Proximity Sensor with PNP open-collector transistor output. It offers normally open output operation, front sensing and 2.5mm maximum sensing range. Thorough adjustment and control of sensing sensitivity greatly reduces individual sensor differences and variations. The work of adjusting sensor positions when using multiple sensors and when sensors have been replaced is much easier. The new integrated construction method used provides shock resistance of 10000m/s² and vibration resistance clears durability tests of between 10 and 500Hz.
- Can be installed with ample space
- Environmental resistance
- Highly resistant to water or oil
- Indicators are easy to see over a wide field of view
- Tightening strength increased with no damage
- Conductor thickness doubled to make wiring much easier
Especificaciones técnicas
Sensor de proximidad inductivo
70°C
PNP-NO
-
24V
24VDC
Módulo
PBT (Polibutileno Tereftalato)
-25°C
To Be Advised
2.1mm
-
2.5mm
12V
12VDC
PNP, NO
Cable
IP68, IP68G
GX-F Series
Documentos técnicos (1)
Legislación y medioambiente
País donde se realizó la mayor parte del proceso de producciónPaís de origen:Japan
País donde se realizó la mayor parte del proceso de producción
RoHS
RoHS
Certificado de conformidad del producto
